Dimensions:
|
Module 22,5mm series ESUC DIN-rail mounting EN50022
|
Tuning:
|
Manual or automatic
|
Material:
|
Box: Polycarbonate V0
|
Alarm mode:
|
Absolute/ threshold, band, upper/lower deviation, Alarms with optional manual reset and activation delay, Loop Break Alarm
|
Weight:
|
Approx. 75 g
|
Double P.I.D:
|
Heating / Cooling with dual P.I.D.
|
Sealing:
|
Box and terminal blocks: IP20
|
Soft-Start:
|
Rising gradient programmable as Degree / hour or fixed output %
|
Operating conditions:
|
Temperature 0-45 °C, humidity 35..95 uR%
|
Communication protocols:
|
Modbus RTU
|
Certifications:
|
CE
|
Software parameter configuration:
|
Software MyPixsysLab |
Control algorithms:
|
ON - OFF with hysteresis, P., P.I., P.I.D., P.D. time proportional
|
|
|
