Power supply: 24...220 V AC / DC ±10% 50/60 Hz - galvanic isolation 2,5KV
Power consumption: 5,5 Watt/VA
Display: 4 digit 0,63" white + Display 5 digit 0,39" red + Display 5 digit 0,33" yellow+ bar graph + 12 signalising leds
Analogue inputs: 1x Ris. 16bit, programmable for thermocouples K, S, R, J, T, E, N, B (automatic compensation of cold junction -25..85°C, accuracy @25°C ±0,2% F.S. or ±1 digit), Thermoresistances PT100, PT500, PT1000, Ni100, PTC1K, NTC10K (B 3435K), Process signals 0/4..20mA (40000 points), 0...1/5/10V (54000 points), 0..60mV (16000 points), Potentiometers F.S. 1/150Kohm (50000 points).
Digital output: 2 x PNP 12VDC - 30mA max
Digital input: 4x PNP
Analogue outputs: -
Serial communication: -

ordering code: 1137
